PV MPPT Controller MPPT-24

320kW, 6-channel MPPT with IP66 and 99.3% efficiency

MPPT-24 photovoltaic MPPT controller with 320kW rated output power, 6 MPPT channels, IP66 protection, and 99.3% EU efficiency. Features wide PV input voltage range and forced air cooling for outdoor solar installations.

Model: MPPT-24

Request a Quote WhatsApp

Key Features

6-Channel MPPT

Six independent MPPT trackers for maximum flexibility

High Efficiency

99.3% EU efficiency rating

Wide Input Range

MPPT voltage range 500-1460V

Outdoor Rated

IP66 protection with C3 corrosion resistance

Specifications

Max PV Array Voltage	1500V
Start-up Voltage	550V
MPPT Voltage Range	500-1460V
Number of MPPT	6
Max MPPT Current	60A
Rated Output Power	320kW
Rated Output Current	240A
EU Efficiency	99.3%
IP Rating	IP66
Cooling	Forced air cooling
Working Temperature	-30°C ~ 60°C
Dimensions (W×D×H)	900×340×620mm
Weight	60kg
Communication	RS485

Applications

Large-scale PV plants

Industrial solar

PV + Storage systems
